Modular Rear Panel: Ultimate Build Flexibility
The LIAN LI O11 Dynamic Mini V2 stands out with its unique modular back panel, allowing you to customize the case layout to fit your specific hardware needs. By swapping the included brackets, you can shift between 3-slot, 5-slot, or 7-slot configurations. This means the chassis can seamlessly transform to support everything from a full-sized ATX motherboard to a compact Mini-ITX setup with extra room for massive liquid cooling hardware.
Dual-Chamber Stealth: Professional Aesthetics
Extensive Cooling Potential: Small but Mighty
Finished in a sleek matte black, the O11 Mini V2 utilizes a dual-chamber design to separate heat-generating components from cables and power delivery. The front and side tempered glass panels provide a continuous, panoramic view of your internal components, while the brushed aluminum accents offer a premium, industrial feel. This layout ensures your core hardware takes center stage, keeping the clutter of power cables and storage drives hidden in the rear.
Don’t let the “Mini” name fool you; this case is engineered for extreme cooling performance. It can accommodate up to nine 120mm fans or a combination of multiple radiators across the top, side, and bottom. Because of its modular nature, you can create massive clearance for thick radiator setups that are usually reserved for much larger cases. The high-airflow design ensures that even the most powerful modern GPUs remain cool during intensive gaming sessions.
Key Specifications
Case Type: Modular Mid Tower.
Motherboard Support: ATX, Micro-ATX, Mini-ITX (Modular configuration).
Power Supply Support: SFX / SFX-L Only (Note: Standard ATX power supplies are not compatible).
Materials: Premium Aluminum, Steel, and 4.0mm Tempered Glass.
Fan Support: Space for up to 9x 120mm fans (Fans not included).
Radiator Support: Top (Up to 360mm), Side (Up to 280mm), Bottom (Up to 360mm).
GPU Clearance: Supports high-end cards up to 395mm in length.
Front I/O: 1x USB 3.1 Type-C, 2x USB 3.0, and HD Audio.
Color: Stealth Black.
| Model No | LIAN LI O11 Dynamic Mini V2 ATX Mid Tower Gaming Case |
| Part No | G99.O11DMIV2X.00 |
| Color | Black |
| Case Material | 2 mm Aluminum Panels, 1 mm Mesh Panels, 4 mm Tempered Glass |
| Case Size | Mid Tower ATX (Approx. 45.38 L chassis volume) |
| Lighting | No Built?In Lighting |
| Motherboard Support | ATX / Back?Connect ATX / Micro?ATX / Mini?ITX |
| Pre?installed Fans | None (Fans not included) |
| Additional Fan Support | Up to 9 Ă— 120 mm Fans (Top: 3; Side: 2; Bottom: 3; Rear: 1) |
| Radiator Support | Top: Up to 360 mm; Side: Up to 240 mm |
| SSD/HDD Support | Drive Cage: 2 Ă— 2.5? or 2 Ă— 3.5?; Behind MB Tray: 2 Ă— 2.5? |
| I/O Ports | USB 3.0 Ă— 2; USB 3.2 Type?C Ă— 1; Audio Ă— 1; Power Button Ă— 1 |
| CPU Cooler Limitation | Up to ~160 mm Height |
| VGA Limitation | Up to ~400 mm Length |
| PSU Limitation | ATX PSU up to 200 mm Length |
| Dust Filters | Bottom Dust Filter Ă— 1 |
| Product Size (Dimension) | Approx. 423.6 Ă— 273.3 Ă— 391.95 mm (D Ă— W Ă— H) |
| Product Weight | Approx. 20 kg |
| Package Content | Case Body, Screws & Accessories Kit, Manuals |
| Warranty | 1 Year ( As per Manufacturer Policy ) |
