Cutting-edge Technology
Incredible Performance2
6GHz for More Capacity
RE815XE takes full advantage of tri-band, empowering up to 96 devices with lightning-fast 5400 Mbps speed.3Â With the 6 GHz band serving as its backhaul, all of your connected devices receive phenomenal connectivity.
| WIRELESS | |
|---|---|
| Working Modes | Range Extender/Access Point |
| HARDWARE FEATURES | |
|---|---|
| Ports | 1 Gigabit Ethernet Port |
| Button | WPS Button, Reset Button |
| Input Power | 100-240V~50/60Hz |
| Power Consumption | 23W |
| Dimensions ( W x D x H ) | 4.2Ă—1.6Ă—13.7 in. (106.6Ă—39.7Ă—348.2 mm) |
| Antenna | 4 External Antennas |
| WIRELESS FEATURES | |
|---|---|
| Wireless Standards | IEEE 802.11ax 6 GHz, IEEE 802.11a/n/ac/ax 5 GHz, IEEE 802.11b/g/n/ax 2.4 GHz |
| Frequency | 2.4GHz and 5GHz and 6GHz |
| Signal Rate | 574 Mbps at 2.4 GHz, 2402 Mbps at 5 GHz, 2402 Mbps at 6 GHz |
| Reception Sensitivity | 6GHz: 11ax HE20 MCS0?-92dBm, 11ax HE20 MCS11?-61dBm 11ax HE40 MCS0?-89dBm, 11ax HE40 MCS11?-58dBm 11ax HE80 MCS0?-86dBm, 11ax HE80 MCS11?-55dBm 11ax HE160 MCS0?-83dBm, 11ax HE160 MCS11?-52dBm 5GHz: 11ax HE20 MCS0?-93dBm, 11ax HE20 MCS11?-62dBm 11ax HE40 MCS0?-90dBm, 11ax HE40 MCS11?-59dBm 11ax HE80 MCS0?-87dBm, 11ax HE80 MCS11?-56dBm 11ax HE160 MCS0?-84dBm, 11ax HE160 MCS11?-53dBm 2.4GHz: 11ax HE20 MCS0?-95dBm, 11ax HE20 MCS11?-64dBm 11ax HE40 MCS0?-92dBm, 11ax HE40 MCS11?-62dBm |
| Wireless Functions | LED Control, Access Control, Power Schedule, Wi-Fi Coverage |
| Wireless Security | 64/128-bit WEP, WPA/WPA-PSK2 encryptions, WPA3 |
| Transmission Power | FCC: 2.4GHz < 30dBm, 5GHz < 30dBm, 6GHz < 30dBm |
| OTHERS | |
|---|---|
| Certification | FCC, RoHS |
| Package Contents | Wi-Fi Range Extender RE815XE Quick Installation Guide |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser |
| Environment | Operating Temperature: 0?~40? (32? ~104?) Storage Temperature: -40?~70? (-40? ~158?) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
